Armen Zambrano: Frontend security — thoughts on Snyk

Mozilla planet - wo, 21/08/2019 - 21:29
Frontend security — thoughts on Snyk

I can’t remember why but few months ago I started looking into keeping my various React projects secure. Here’s some of what I discovered (more to come). I hope some will be valuable to you.

A while ago I discovered Snyk and I hooked it up my various projects with it. Snyk sends me a weekly security summary with the breakdown of various security issues across all of my projects.

<figcaption>This is part of Snyk’s weekly report I receive in my inbox</figcaption>

Snyk also gives me context about the particular security issues found:

<figcaption>This is extremely useful if you want to understand the security issue</figcaption>

It also analyzes my dependencies on a per-PR level:

<figcaption>Safey? Check! — This is a GitHub PR check (like Travis)</figcaption>

Other features that I’ve tried from Snyk:

  1. It sends you an email when there’s a vulnerable package (no need to wait for the weekly report)
  2. Open PRs upgrading vulnerable packages when possible
  3. Patch your code while there’s no published package with a fix
<figcaption>This is a summary for your project — it shows that a PR can be opened</figcaption>

The above features I have tried and I decided not to use them for the following reasons (listed in the same order as above):

  1. As a developer I already get enough interruptions in a week. I don’t need to be notified for every single security issue in my dependency tree. My projects don’t deal with anything sensitive, thus, I’m OK with waiting to deal with them at the beginning of the week
  2. The PR opened by Snyk does not work well with Yarn since it does not update the yarn.lock file, thus, requirying me to fetch the PR, run yarn install and push it back (This wastes my time)
  3. The feature to patch your code (Runtime protection or snyk protect) adds a very high set up cost (1–2 minutes) everytime you need to run yarn install. This is because it analyzes all your dependencies and patches your code in-situ. This gets on the way of my development workflow.

Overall I’m very satisfied with Snyk and I highly recommend using it.

In the following posts I’m thinking of speaking on:

  • How Renovate can help reduce the burden of keeping your projects up-to-date (reducing security work later on)
  • Differences between GitHub’s security tab (DependaBot) and Snyk
  • npm audit, yarn audit & snyk test

NOTE: This post is not sponsored by Snyk. I love what they do, I root for them and I hope they soon fix the issues I mention above.

Categorieën: Mozilla-nl planet

Support.Mozilla.Org: Introducing Bryce and Brady

Mozilla planet - wo, 21/08/2019 - 18:18

Hello SUMO Community,

I’m thrilled to share this update with you today. Bryce and Brady have joined us last week and will be able to help out on Support for some of the new efforts Mozilla are working on towards creating a connected and integrated Firefox experience.

They are going to be involved with new products, but also they won’t forget to put extra effort in providing support on forums and as well as serving as an escalation point for hard to solve issues.

Here is a short introduction to Brady and Bryce:

Hi! My name is Brady, and I am one of the new members of the SUMO team. I am originally from Boise, Idaho and am currently going to school for a Computer Science degree at Boise State. In my free time, I’m normally playing video games, writing, drawing, or enjoying the Sawtooths. I will be providing support for Mozilla products and for the SUMO team.

Hello!  My name is Bryce, I was born and raised in San Diego and I reside in Boise, Idaho.  Growing up I spent a good portion of my life trying to be the best sponger(boogie boarder) and longboarder in North County San Diego.  While out in the ocean I had all sorts of run-ins with sea creatures; but nothing to scary. I am also an IN-N-Out fan, as you may find me sporting their merchandise with boardshorts and the such.   I am truly excited to be part of this amazing group of fun loving folks and I am looking forward to getting to know everyone.

Please welcome them warmly!

Categorieën: Mozilla-nl planet

Hacks.Mozilla.Org: WebAssembly Interface Types: Interoperate with All the Things!

Mozilla planet - wo, 21/08/2019 - 18:02

People are excited about running WebAssembly outside the browser.

That excitement isn’t just about WebAssembly running in its own standalone runtime. People are also excited about running WebAssembly from languages like Python, Ruby, and Rust.

Why would you want to do that? A few reasons:

  • Make “native” modules less complicated
    Runtimes like Node or Python’s CPython often allow you to write modules in low-level languages like C++, too. That’s because these low-level languages are often much faster. So you can use native modules in Node, or extension modules in Python. But these modules are often hard to use because they need to be compiled on the user’s device. With a WebAssembly “native” module, you can get most of the speed without the complication.
  • Make it easier to sandbox native code
    On the other hand, low-level languages like Rust wouldn’t use WebAssembly for speed. But they could use it for security. As we talked about in the WASI announcement, WebAssembly gives you lightweight sandboxing by default. So a language like Rust could use WebAssembly to sandbox native code modules.
  • Share native code across platforms
    Developers can save time and reduce maintainance costs if they can share the same codebase across different platforms (e.g. between the web and a desktop app). This is true for both scripting and low-level languages. And WebAssembly gives you a way to do that without making things slower on these platforms.

Scripting languages like Python and Ruby saying 'We like WebAssembly's speed', low-level languages like Rust and C++ saying, 'and we like the security it could give us' and all of them saying 'and we all want to make developers more effective'

So WebAssembly could really help other languages with important problems.

But with today’s WebAssembly, you wouldn’t want to use it in this way. You can run WebAssembly in all of these places, but that’s not enough.

Right now, WebAssembly only talks in numbers. This means the two languages can call each other’s functions.

But if a function takes or returns anything besides numbers, things get complicated. You can either:

  • Ship one module that has a really hard-to-use API that only speaks in numbers… making life hard for the module’s user.
  • Add glue code for every single environment you want this module to run in… making life hard for the module’s developer.

But this doesn’t have to be the case.

It should be possible to ship a single WebAssembly module and have it run anywhere… without making life hard for either the module’s user or developer.

user saying 'what even is this API?' vs developer saying 'ugh, so much glue code to worry about' vs both saying 'wait, it just works?'

So the same WebAssembly module could use rich APIs, using complex types, to talk to:

  • Modules running in their own native runtime (e.g. Python modules running in a Python runtime)
  • Other WebAssembly modules written in different source languages (e.g. a Rust module and a Go module running together in the browser)
  • The host system itself (e.g. a WASI module providing the system interface to an operating system or the browser’s APIs)

 logos for different runtimes (Ruby, php, and Python), other wasm files compiled from Rust and Go, and host systems like the OS or browser

And with a new, early-stage proposal, we’re seeing how we can make this Just Work™, as you can see in this demo.

So let’s take a look at how this will work. But first, let’s look at where we are today and the problems that we’re trying to solve.

WebAssembly talking to JS

WebAssembly isn’t limited to the web. But up to now, most of WebAssembly’s development has focused on the Web.

That’s because you can make better designs when you focus on solving concrete use cases. The language was definitely going to have to run on the Web, so that was a good use case to start with.

This gave the MVP a nicely contained scope. WebAssembly only needed to be able to talk to one language—JavaScript.

And this was relatively easy to do. In the browser, WebAssembly and JS both run in the same engine, so that engine can help them efficiently talk to each other.

A js file asking the engine to call a WebAssembly function

The engine asking the WebAssembly file to run the function

But there is one problem when JS and WebAssembly try to talk to each other… they use different types.

Currently, WebAssembly can only talk in numbers. JavaScript has numbers, but also quite a few more types.

And even the numbers aren’t the same. WebAssembly has 4 different kinds of numbers: int32, int64, float32, and float64. JavaScript currently only has Number (though it will soon have another number type, BigInt).

The difference isn’t just in the names for these types. The values are also stored differently in memory.

First off, in JavaScript any value, no matter the type, is put in something called a box (and I explained boxing more in another article).

WebAssembly, in contrast, has static types for its numbers. Because of this, it doesn’t need (or understand) JS boxes.

This difference makes it hard to communicate with each other.

JS asking wasm to add 5 and 7, and Wasm responding with 9.2368828e+18

But if you want to convert a value from one number type to the other, there are pretty straightforward rules.

Because it’s so simple, it’s easy to write down. And you can find this written down in WebAssembly’s JS API spec.

A large book that has mappings between the wasm number types and the JS number types

This mapping is hardcoded in the engines.

It’s kind of like the engine has a reference book. Whenever the engine has to pass parameters or return values between JS and WebAssembly, it pulls this reference book off the shelf to see how to convert these values.

JS asking the engine to call wasm's add function with 5 and 7, and the engine looking up how to do conversions in the book

Having such a limited set of types (just numbers) made this mapping pretty easy. That was great for an MVP. It limited how many tough design decisions needed to be made.

But it made things more complicated for the developers using WebAssembly. To pass strings between JS and WebAssembly, you had to find a way to turn the strings into an array of numbers, and then turn an array of numbers back into a string. I explained this in a previous post.

JS putting numbers into WebAssembly's memory

This isn’t difficult, but it is tedious. So tools were built to abstract this away.

For example, tools like Rust’s wasm-bindgen and Emscripten’s Embind automatically wrap the WebAssembly module with JS glue code that does this translation from strings to numbers.

JS file complaining about having to pass a string to Wasm, and the JS glue code offering to do all the work

And these tools can do these kinds of transformations for other high-level types, too, such as complex objects with properties.

This works, but there are some pretty obvious use cases where it doesn’t work very well.

For example, sometimes you just want to pass a string through WebAssembly. You want a JavaScript function to pass a string to a WebAssembly function, and then have WebAssembly pass it to another JavaScript function.

Here’s what needs to happen for that to work:

  1. the first JavaScript function passes the string to the JS glue code

  2. the JS glue code turns that string object into numbers and then puts those numbers into linear memory

  3. then passes a number (a pointer to the start of the string) to WebAssembly

  4. the WebAssembly function passes that number over to the JS glue code on the other side

  5. the second JavaScript function pulls all of those numbers out of linear memory and then decodes them back into a string object

  6. which it gives to the second JS function

JS file passing string 'Hello' to JS glue code
JS glue code turning string into numbers and putting that in linear memory
JS glue code telling engine to pass 2 to wasm
Wasm telling engine to pass 2 to JS glue code
JS glue code taking bytes from linear memory and turning them back into a string
JS glue code passing string to JS file

So the JS glue code on one side is just reversing the work it did on the other side. That’s a lot of work to recreate what’s basically the same object.

If the string could just pass straight through WebAssembly without any transformations, that would be way easier.

WebAssembly wouldn’t be able to do anything with this string—it doesn’t understand that type. We wouldn’t be solving that problem.

But it could just pass the string object back and forth between the two JS functions, since they do understand the type.

So this is one of the reasons for the WebAssembly reference types proposal. That proposal adds a new basic WebAssembly type called anyref.

With an anyref, JavaScript just gives WebAssembly a reference object (basically a pointer that doesn’t disclose the memory address). This reference points to the object on the JS heap. Then WebAssembly can pass it to other JS functions, which know exactly how to use it.

JS passing a string to Wasm and the engine turning it into a pointer
Wasm passing the string to a different JS file, and the engine just passes the pointer on

So that solves one of the most annoying interoperability problems with JavaScript. But that’s not the only interoperability problem to solve in the browser.

There’s another, much larger, set of types in the browser. WebAssembly needs to be able to interoperate with these types if we’re going to have good performance.

WebAssembly talking directly to the browser

JS is only one part of the browser. The browser also has a lot of other functions, called Web APIs, that you can use.

Behind the scenes, these Web API functions are usually written in C++ or Rust. And they have their own way of storing objects in memory.

Web APIs’ parameters and return values can be lots of different types. It would be hard to manually create mappings for each of these types. So to simplify things, there’s a standard way to talk about the structure of these types—Web IDL.

When you’re using these functions, you’re usually using them from JavaScript. This means you are passing in values that use JS types. How does a JS type get converted to a Web IDL type?

Just as there is a mapping from WebAssembly types to JavaScript types, there is a mapping from JavaScript types to Web IDL types.

So it’s like the engine has another reference book, showing how to get from JS to Web IDL. And this mapping is also hardcoded in the engine.

A book that has mappings between the JS types and Web IDL types

For many types, this mapping between JavaScript and Web IDL is pretty straightforward. For example, types like DOMString and JS’s String are compatible and can be mapped directly to each other.

Now, what happens when you’re trying to call a Web API from WebAssembly? Here’s where we get to the problem.

Currently, there is no mapping between WebAssembly types and Web IDL types. This means that, even for simple types like numbers, your call has to go through JavaScript.

Here’s how this works:

  1. WebAssembly passes the value to JS.
  2. In the process, the engine converts this value into a JavaScript type, and puts it in the JS heap in memory
  3. Then, that JS value is passed to the Web API function. In the process, the engine converts the JS value into a Web IDL type, and puts it in a different part of memory, the renderer’s heap.

Wasm passing number to JS
Engine converting the int32 to a Number and putting it in the JS heap
Engine converting the Number to a double, and putting that in the renderer heap

This takes more work than it needs to, and also uses up more memory.

There’s an obvious solution to this—create a mapping from WebAssembly directly to Web IDL. But that’s not as straightforward as it might seem.

For simple Web IDL types like boolean and unsigned long (which is a number), there are clear mappings from WebAssembly to Web IDL.

But for the most part, Web API parameters are more complex types. For example, an API might take a dictionary, which is basically an object with properties, or a sequence, which is like an array.

To have a straightforward mapping between WebAssembly types and Web IDL types, we’d need to add some higher-level types. And we are doing that—with the GC proposal. With that, WebAssembly modules will be able to create GC objects—things like structs and arrays—that could be mapped to complicated Web IDL types.

But if the only way to interoperate with Web APIs is through GC objects, that makes life harder for languages like C++ and Rust that wouldn’t use GC objects otherwise. Whenever the code interacts with a Web API, it would have to create a new GC object and copy values from its linear memory into that object.

That’s only slightly better than what we have today with JS glue code.

We don’t want JS glue code to have to build up GC objects—that’s a waste of time and space. And we don’t want the WebAssembly module to do that either, for the same reasons.

We want it to be just as easy for languages that use linear memory (like Rust and C++) to call Web APIs as it is for languages that use the engine’s built-in GC. So we need a way to create a mapping between objects in linear memory and Web IDL types, too.

There’s a problem here, though. Each of these languages represents things in linear memory in different ways. And we can’t just pick one language’s representation. That would make all the other languages less efficient.

someone standing between the names of linear memory languages like C, C++, and Rust, pointing to Rust and saying 'I pick... that one!'. A red arrow points to the person saying 'bad idea'

But even though the exact layout in memory for these things is often different, there are some abstract concepts that they usually share in common.

For example, for strings the language often has a pointer to the start of the string in memory, and the length of the string. And even if the string has a more complicated internal representation, it usually needs to convert strings into this format when calling external APIs anyways.

This means we can reduce this string down to a type that WebAssembly understands… two i32s.

The string Hello in linear memory, with an offset of 2 and length of 5. Red arrows point to offset and length and say 'types that WebAssembly understands!'

We could hardcode a mapping like this in the engine. So the engine would have yet another reference book, this time for WebAssembly to Web IDL mappings.

But there’s a problem here. WebAssembly is a type-checked language. To keep things secure, the engine has to check that the calling code passes in types that match what the callee asks for.

This is because there are ways for attackers to exploit type mismatches and make the engine do things it’s not supposed to do.

If you’re calling something that takes a string, but you try to pass the function an integer, the engine will yell at you. And it should yell at you.

So we need a way for the module to explicitly tell the engine something like: “I know Document.createElement() takes a string. But when I call it, I’m going to pass you two integers. Use these to create a DOMString from data in my linear memory. Use the first integer as the starting address of the string and the second as the length.”

This is what the Web IDL proposal does. It gives a WebAssembly module a way to map between the types that it uses and Web IDL’s types.

These mappings aren’t hardcoded in the engine. Instead, a module comes with its own little booklet of mappings.

Wasm file handing a booklet to the engine and saying `Here's a little guidebook. It will tell you how to translate my types to interface types`

So this gives the engine a way to say “For this function, do the type checking as if these two integers are a string.”

The fact that this booklet comes with the module is useful for another reason, though.

Sometimes a module that would usually store its strings in linear memory will want to use an anyref or a GC type in a particular case… for example, if the module is just passing an object that it got from a JS function, like a DOM node, to a Web API.

So modules need to be able to choose on a function-by-function (or even even argument-by-argument) basis how different types should be handled. And since the mapping is provided by the module, it can be custom-tailored for that module.

Wasm telling engine 'Read carefully... For some function that take DOMStrings, I'll give you two numbers. For others, I'll just give you the DOMString that JS gave to me.'

How do you generate this booklet?

The compiler takes care of this information for you. It adds a custom section to the WebAssembly module. So for many language toolchains, the programmer doesn’t have to do much work.

For example, let’s look at how the Rust toolchain handles this for one of the simplest cases: passing a string into the alert function.

#[wasm_bindgen] extern "C" { fn alert(s: &str); }

The programmer just has to tell the compiler to include this function in the booklet using the annotation #[wasm_bindgen]. By default, the compiler will treat this as a linear memory string and add the right mapping for us. If we needed it to be handled differently (for example, as an anyref) we’d have to tell the compiler using a second annotation.

So with that, we can cut out the JS in the middle. That makes passing values between WebAssembly and Web APIs faster. Plus, it means we don’t need to ship down as much JS.

And we didn’t have to make any compromises on what kinds of languages we support. It’s possible to have all different kinds of languages that compile to WebAssembly. And these languages can all map their types to Web IDL types—whether the language uses linear memory, or GC objects, or both.

Once we stepped back and looked at this solution, we realized it solved a much bigger problem.

WebAssembly talking to All The Things

Here’s where we get back to the promise in the intro.

Is there a feasible way for WebAssembly to talk to all of these different things, using all these different type systems?

 logos for different runtimes (Ruby, php, and Python), other wasm files compiled from Rust and Go, and host systems like the OS or browser

Let’s look at the options.

You could try to create mappings that are hardcoded in the engine, like WebAssembly to JS and JS to Web IDL are.

But to do that, for each language you’d have to create a specific mapping. And the engine would have to explicitly support each of these mappings, and update them as the language on either side changes. This creates a real mess.

This is kind of how early compilers were designed. There was a pipeline for each source language to each machine code language. I talked about this more in my first posts on WebAssembly.

We don’t want something this complicated. We want it to be possible for all these different languages and platforms to talk to each other. But we need it to be scalable, too.

So we need a different way to do this… more like modern day compiler architectures. These have a split between front-end and back-end. The front-end goes from the source language to an abstract intermediate representation (IR). The back-end goes from that IR to the target machine code.

This is where the insight from Web IDL comes in. When you squint at it, Web IDL kind of looks like an IR.

Now, Web IDL is pretty specific to the Web. And there are lots of use cases for WebAssembly outside the web. So Web IDL itself isn’t a great IR to use.

But what if you just use Web IDL as inspiration and create a new set of abstract types?

This is how we got to the WebAssembly interface types proposal.

Diagram showing WebAssembly interface types in the middle. On the left is a wasm module, which could be compiled from Rust, Go, C, etc. Arrows point from these options to the types in the middle. On the right are host languages like JS, Python, and Ruby; host platforms like .NET, Node, and operating systems, and more wasm modules. Arrows point from these options to the types in the middle.

These types aren’t concrete types. They aren’t like the int32 or float64 types in WebAssembly today. There are no operations on them in WebAssembly.

For example, there won’t be any string concatenation operations added to WebAssembly. Instead, all operations are performed on the concrete types on either end.

There’s one key point that makes this possible: with interface types, the two sides aren’t trying to share a representation. Instead, the default is to copy values between one side and the other.

saying 'since this is a string in linear memory, I know how to manipulate it' and browser saying 'since this is a DOMString, I know how to manipulate it'

There is one case that would seem like an exception to this rule: the new reference values (like anyref) that I mentioned before. In this case, what is copied between the two sides is the pointer to the object. So both pointers point to the same thing. In theory, this could mean they need to share a representation.

In cases where the reference is just passing through the WebAssembly module (like the anyref example I gave above), the two sides still don’t need to share a representation. The module isn’t expected to understand that type anyway… just pass it along to other functions.

But there are times where the two sides will want to share a representation. For example, the GC proposal adds a way to create type definitions so that the two sides can share representations. In these cases, the choice of how much of the representation to share is up to the developers designing the APIs.

This makes it a lot easier for a single module to talk to many different languages.

In some cases, like the browser, the mapping from the interface types to the host’s concrete types will be baked into the engine.

So one set of mappings is baked in at compile time and the other is handed to the engine at load time.

Engine holding Wasm's mapping booklet and its own mapping reference book for Wasm Interface Types to Web IDL, saying 'So this maps to a string? Ok, I can take it from here to the DOMString that the function is asking for using my hardcoded bindings'

But in other cases, like when two WebAssembly modules are talking to each other, they both send down their own little booklet. They each map their functions’ types to the abstract types.

Engine reaching for mapping booklets from two wasm files, saying 'Ok, let's see how these map to each other'

This isn’t the only thing you need to enable modules written in different source languages to talk to each other (and we’ll write more about this in the future) but it is a big step in that direction.

So now that you understand why, let’s look at how.

What do these interface types actually look like?

Before we look at the details, I should say again: this proposal is still under development. So the final proposal may look very different.

Two construction workers with a sign that says 'Use caution'

Also, this is all handled by the compiler. So even when the proposal is finalized, you’ll only need to know what annotations your toolchain expects you to put in your code (like in the wasm-bindgen example above). You won’t really need to know how this all works under the covers.

But the details of the proposal are pretty neat, so let’s dig into the current thinking.

The problem to solve

The problem we need to solve is translating values between different types when a module is talking to another module (or directly to a host, like the browser).

There are four places where we may need to do a translation:

For exported functions

  • accepting parameters from the caller
  • returning values to the caller

For imported functions

  • passing parameters to the function
  • accepting return values from the function

And you can think about each of these as going in one of two directions:

  • Lifting, for values leaving the module. These go from a concrete type to an interface type.
  • Lowering, for values coming into the module. These go from an interface type to a concrete type.

Telling the engine how to transform between concrete types and interface types

So we need a way to tell the engine which transformations to apply to a function’s parameters and return values. How do we do this?

By defining an interface adapter.

For example, let’s say we have a Rust module compiled to WebAssembly. It exports a greeting_ function that can be called without any parameters and returns a greeting.

Here’s what it would look like (in WebAssembly text format) today.

a Wasm module that exports a function that returns two numbers. See proposal linked above for details.

So right now, this function returns two integers.

But we want it to return the string interface type. So we add something called an interface adapter.

If an engine understands interface types, then when it sees this interface adapter, it will wrap the original module with this interface.

an interface adapter that returns a string. See proposal linked above for details.

It won’t export the greeting_ function anymore… just the greeting function that wraps the original. This new greeting function returns a string, not two numbers.

This provides backwards compatibility because engines that don’t understand interface types will just export the original greeting_ function (the one that returns two integers).

How does the interface adapter tell the engine to turn the two integers into a string?

It uses a sequence of adapter instructions.

Two adapter instructions inside of the adapter function. See proposal linked above for details.

The adapter instructions above are two from a small set of new instructions that the proposal specifies.

Here’s what the instructions above do:

  1. Use the call-export adapter instruction to call the original greeting_ function. This is the one that the original module exported, which returned two numbers. These numbers get put on the stack.
  2. Use the memory-to-string adapter instruction to convert the numbers into the sequence of bytes that make up the string. We have to specifiy “mem” here because a WebAssembly module could one day have multiple memories. This tells the engine which memory to look in. Then the engine takes the two integers from the top of the stack (which are the pointer and the length) and uses those to figure out which bytes to use.

This might look like a full-fledged programming language. But there is no control flow here—you don’t have loops or branches. So it’s still declarative even though we’re giving the engine instructions.

What would it look like if our function also took a string as a parameter (for example, the name of the person to greet)?

Very similar. We just change the interface of the adapter function to add the parameter. Then we add two new adapter instructions.

Here’s what these new instructions do:

  1. Use the arg.get instruction to take a reference to the string object and put it on the stack.
  2. Use the string-to-memory instruction to take the bytes from that object and put them in linear memory. Once again, we have to tell it which memory to put the bytes into. We also have to tell it how to allocate the bytes. We do this by giving it an allocator function (which would be an export provided by the original module).

One nice thing about using instructions like this: we can extend them in the future… just as we can extend the instructions in WebAssembly core. We think the instructions we’re defining are a good set, but we aren’t committing to these being the only instruct for all time.

If you’re interested in understanding more about how this all works, the explainer goes into much more detail.

Sending these instructions to the engine

Now how do we send this to the engine?

These annotations gets added to the binary file in a custom section.

A file split in two. The top part is labeled 'known sections, e.g. code, data'. The bottom part is labeled 'custom sections, e.g. interface adapter'

If an engine knows about interface types, it can use the custom section. If not, the engine can just ignore it, and you can use a polyfill which will read the custom section and create glue code.

How is this different than CORBA, Protocol Buffers, etc?

There are other standards that seem like they solve the same problem—for example CORBA, Protocol Buffers, and Cap’n Proto.

How are those different? They are solving a much harder problem.

They are all designed so that you can interact with a system that you don’t share memory with—either because it’s running in a different process or because it’s on a totally different machine across the network.

This means that you have to be able to send the thing in the middle—the “intermediate representation” of the objects—across that boundary.

So these standards need to define a serialization format that can efficiently go across the boundary. That’s a big part of what they are standardizing.

Two computers with wasm files on them and multiple lines flowing into a single line connecting connecting them. The single line represents serialization and is labelled 'IR'

Even though this looks like a similar problem, it’s actually almost the exact inverse.

With interface types, this “IR” never needs to leave the engine. It’s not even visible to the modules themselves.

The modules only see the what the engine spits out for them at the end of the process—what’s been copied to their linear memory or given to them as a reference. So we don’t have to tell the engine what layout to give these types—that doesn’t need to be specified.

What is specified is the way that you talk to the engine. It’s the declarative language for this booklet that you’re sending to the engine.

Two wasm files with arrows pointing to the word 'IR' with no line between, because there is no serialization happening.

This has a nice side effect: because this is all declarative, the engine can see when a translation is unnecessary—like when the two modules on either side are using the same type—and skip the translation work altogether.

The engine looking at the booklets for a Rust module and a Go module and saying 'Ooh, you’re both using linear memory for this string... I’ll just do a quick copy between your memories, then'

How can you play with this today?

As I mentioned above, this is an early stage proposal. That means things will be changing rapidly, and you don’t want to depend on this in production.

But if you want to start playing with it, we’ve implemented this across the toolchain, from production to consumption:

  • the Rust toolchain
  • wasm-bindgen
  • the Wasmtime WebAssembly runtime

And since we maintain all these tools, and since we’re working on the standard itself, we can keep up with the standard as it develops.

Even though all these parts will continue changing, we’re making sure to synchronize our changes to them. So as long as you use up-to-date versions of all of these, things shouldn’t break too much.

Construction worker saying 'Just be careful and stay on the path'

So here are the many ways you can play with this today. For the most up-to-date version, check out this repo of demos.

Thank you
  • Thank you to the team who brought all of the pieces together across all of these languages and runtimes: Alex Crichton, Yury Delendik, Nick Fitzgerald, Dan Gohman, and Till Schneidereit
  • Thank you to the proposal co-champions and their colleagues for their work on the proposal: Luke Wagner, Francis McCabe, Jacob Gravelle, Alex Crichton, and Nick Fitzgerald
  • Thank you to my fantastic collaborators, Luke Wagner and Till Schneidereit, for their invaluable input and feedback on this article

The post WebAssembly Interface Types: Interoperate with All the Things! appeared first on Mozilla Hacks - the Web developer blog.

Categorieën: Mozilla-nl planet

The Mozilla Blog: Mozilla takes action to protect users in Kazakhstan

Mozilla planet - wo, 21/08/2019 - 12:01

Today, Mozilla and Google took action to protect the online security and privacy of individuals in Kazakhstan. Together the companies deployed technical solutions within Firefox and Chrome to block the Kazakhstan government’s ability to intercept internet traffic within the country.

The response comes after credible reports that internet service providers in Kazakhstan have required people in the country to download and install a government-issued certificate on all devices and in every browser in order to access the internet. This certificate is not trusted by either of the companies, and once installed, allowed the government to decrypt and read anything a user types or posts, including intercepting their account information and passwords. This targeted people visiting popular sites Facebook, Twitter and Google, among others.

“People around the world trust Firefox to protect them as they navigate the internet, especially when it comes to keeping them safe from attacks like this that undermine their security. We don’t take actions like this lightly, but protecting our users and the integrity of the web is the reason Firefox exists.” — Marshall Erwin, Senior Director of Trust and Security, Mozilla

“We will never tolerate any attempt, by any organization—government or otherwise—to compromise Chrome users’ data. We have implemented protections from this specific issue, and will always take action to secure our users around the world.” — Parisa Tabriz, Senior Engineering Director, Chrome

This is not the first attempt by the Kazakhstan government to intercept the internet traffic of everyone in the country. In 2015, the Kazakhstan government attempted to have a root certificate included in Mozilla’s trusted root store program. After it was discovered that they were intending to use the certificate to intercept user data, Mozilla denied the request. Shortly after, the government forced citizens to manually install its certificate but that attempt failed after organizations took legal action.

Each company will deploy a technical solution unique to its browser. For additional information on those solutions please see the below links.


Russian: Если вы хотите ознакомиться с этим текстом на русском языке, нажмите здесь.

Kazakh: Бұл постыны қазақ тілінде мына жерден оқыңыз.





The post Mozilla takes action to protect users in Kazakhstan appeared first on The Mozilla Blog.

Categorieën: Mozilla-nl planet

Mozilla Security Blog: Protecting our Users in Kazakhstan

Mozilla planet - wo, 21/08/2019 - 12:00

Russian translation: Если вы хотите ознакомиться с этим текстом на русском языке, нажмите здесь.

Kazakh translation: Бұл постыны қазақ тілінде мына жерден оқыңыз.

In July, a Firefox user informed Mozilla of a security issue impacting Firefox users in Kazakhstan: They stated that Internet Service Providers (ISPs) in Kazakhstan had begun telling their customers that they must install a government-issued root certificate on their devices. What the ISPs didn’t tell their customers was that the certificate was being used to intercept network communications. Other users and researchers confirmed these claims, and listed 3 dozen popular social media and communications sites that were affected.

The security and privacy of HTTPS encrypted communications in Firefox and other browsers relies on trusted Certificate Authorities (CAs) to issue website certificates only to someone that controls the domain name or website. For example, you and I can’t obtain a trusted certificate for because Mozilla has strict policies for all CAs trusted by Firefox which only allow an authorized person to get a certificate for that domain. However, when a user in Kazakhstan installs the root certificate provided by their ISP, they are choosing to trust a CA that doesn’t have to follow any rules and can issue a certificate for any website to anyone. This enables the interception and decryption of network communications between Firefox and the website, sometimes referred to as a Monster-in-the-Middle (MITM) attack.

We believe this act undermines the security of our users and the web, and it directly contradicts Principle 4 of the Mozilla Manifesto that states, “Individuals’ security and privacy on the internet are fundamental and must not be treated as optional.”

To protect our users, Firefox, together with Chrome, will block the use of the Kazakhstan root CA certificate. This means that it will not be trusted by Firefox even if the user has installed it. We believe this is the appropriate response because users in Kazakhstan are not being given a meaningful choice over whether to install the certificate and because this attack undermines the integrity of a critical network security mechanism.  When attempting to access a website that responds with this certificate, Firefox users will see an error message stating that the certificate should not be trusted.

We encourage users in Kazakhstan affected by this change to research the use of virtual private network (VPN) software, or the Tor Browser, to access the Web. We also strongly encourage anyone who followed the steps to install the Kazakhstan government root certificate to remove it from your devices and to immediately change your passwords, using a strong, unique password for each of your online accounts.

The post Protecting our Users in Kazakhstan appeared first on Mozilla Security Blog.

Categorieën: Mozilla-nl planet

Cameron Kaiser: FPR16 delays

Mozilla planet - wo, 21/08/2019 - 05:46
FPR16 was supposed to reach you in beta sometime tomorrow but I found a reproducible crash in the optimized build, probably due to one of my vain attempts to fix JavaScript bugs. I'm still investigating exactly which change(s) were responsible. We should still make the deadline (September 3) to be concurrent with the 60.9/68.1 ESRs, but there will not be much of a beta testing period and I don't anticipate it being available until probably at least Friday or Saturday. More later.

While you're waiting, read about today's big OpenPOWER announcement. Isn't it about time for a modern PowerPC under your desk?

Categorieën: Mozilla-nl planet

Mozilla GFX: moz://gfx newsletter #47

Mozilla planet - ma, 19/08/2019 - 17:33

Hi there! Time for another mozilla graphics newsletter. In the comments section of the previous newsletter, Michael asked about the relation between WebRender and WebGL, I’ll try give a short answer here.

Both WebRender and WebGL need access to the GPU to do their work. At the moment both of them use the OpenGL API, either directly or through ANGLE which emulates OpenGL on top of D3D11. They, however, each work with their own OpenGL context. Frames produced with WebGL are sent to WebRender as texture handles. WebRender, at the API level, has a single entry point for images, video frames, canvases, in short for every grid of pixels in some flavor of RGB format, be them CPU-side buffers or already in GPU memory as is normally the case for WebGL. In order to share textures between separate OpenGL contexts we rely on platform-specific APIs such as EGLImage and DXGI.

Beyond that there isn’t any fancy interaction between WebGL and WebRender. The latter sees the former as a image producer just like 2D canvases, video decoders and plain static images.

What’s new in gfx Wayland and hidpi improvements on Linux
  • Martin Stransky made a proof of concept implementation of DMABuf textures in Gecko’s IPC mechanism. This dmabuf EGL texture backend on Wayland is similar what we have on Android/Mac. Dmabuf buffers can be shared with main/compositor process, can be bound as a render target or texture and can be located at GPU memory. The same dma buf buffer can be also used as hardware overlay when it’s attached to wl_surface/wl_subsurface as wl_buffer.
  • Jan Horak fixed a bug that prevented tabs from rendering after restoring a minimized window.
  • Jan Horak fixed the window parenting hierarchy with Wayland.
  • Jan Horak fixed a bug with hidpi that was causing select popups to render incorrectly after scrolling.
WebGL multiview rendering

WebGL’s multiview rendering extension has been approved by the working group and it’s implementation by Jeff Gilbert will be shipping in Firefox 70.
This extension allows more efficient rendering into multiple viewports, which is most commonly use by VR/AR for rendering both eyes at the same time.

Better high dynamic range support

Jean Yves landed the first part of his HDR work (a set of 14 patches). While we can’t yet output HDR content to HDR screen, this work greatly improved the correctness of the conversion from various HDR formats to low dynamic range sRGB.

You can follow progress on the color space meta bug.

What’s new in WebRender

WebRender is a GPU based 2D rendering engine for web written in Rust, currently powering Firefox‘s rendering engine as well as the research web browser servo.

If you are curious about the state of WebRender on a particular platform, up to date information is available at

Speaking of which, darkspirit enabled webrender on Nightly for Nvidia+Nouveau drivers linux users in Firefox Nightly.

More filters in WebRender

When We run into a primitive that isn’t supported by WebRender, we make it go through software fallback implementation which can be slow for some things. SVG filters are a good example of primitives that perform much better if implemented on the GPU in WebRender.
Connor Brewster has been working on implementing a number of SVG filters in WebRender:

See the SVG filters in WebRender meta bug.

Texture swizzling and allocation

WebRender previously only worked with BGRA for color textures. Unfortunately this format is optimal on some platforms but sub-optimal (or even unsupported) on others. So a conversion sometimes has to happen and this conversion if done by the driver can be very costly.

Kvark reworked the texture caching logic to support using and swizzling between different formats (for example RGBA and BGRA).
A document that landed with the implementation provides more details about the approach and context.

Kvark also improved the texture cache allocation behavior.

Kvark also landed various refactorings (1), (2), (3), (4).

Android improvements

Jamie fixed emoji rendering on webrender on android and continues investigating driver issues on Adreno 3xx devices.

Displaylist serialization

Dan replaced bincode in our DL IPC code with a new bespoke and private serialization library (peek-poke), ending the terrible reign of the secret serde deserialize_in_place hacks and our fork of serde_derive.

Picture caching improvements

Glenn landed several improvements and fixes to the picture caching infrastructure:

  • Bug 1566712 – Fix quality issueswith picture caching when transform has fractional offsets.
  • Bug 1572197 – Fix world clip region for preserve-3d items with picture caching.
  • Bug 1566901 – Make picture caching more robust to float issues.
  • Bug 1567472 – Fix bug in preserve-3d batching code in WebRender.
Font rendering improvements

Lee landed quite a few font related patches:

  • Bug 1569950 – Only partially clear WR glyph caches if it is not necessary to fully clear.
  • Bug 1569174 – Disable embedded bitmaps if ClearType rendering mode is forced.
  • Bug 1568841 – Force GDI parameters for GDI render mode.
  • Bug 1568858 – Always stretch box shadows except for Cairo.
  • Bug 1568841 – Don’t use enhanced contrast on GDI fonts.
  • Bug 1553818 – Use GDI ClearType contrast for GDI font gamma.
  • Bug 1565158 – Allow forcing DWrite symmetric rendering mode.
  • Bug 1563133 – Limit the GlyphBuffer capacity.
  • Bug 1560520 – Limit the size of WebRender’s glyph cache.
  • Bug 1566449 – Don’t reverse glyphs in GlyphBuffer for RTL.
  • Bug 1566528 – Clamp the amount of synthetic bold extra strikes.
  • Bug 1553228 – Don’t free the result of FcPatternGetString.
Various fixes and improvements
  • Gankra fixed an issue with addon popups and document splitting.
  • Sotaro prevented some unnecessary composites on out-of-viewport external image updates.
  • Nical fixed an integer oveflow causing the browser to freeze
  • Nical improved the overlay profiler by showing more relevant numbers when the timings are noisy.
  • Nical fixed corrupted rendering of progressively loaded images.
  • Nical added a fast path when none of the primitives of an image batch need anti-aliasing or repetition.
Categorieën: Mozilla-nl planet

Wladimir Palant: Kaspersky in the Middle - what could possibly go wrong?

Mozilla planet - ma, 19/08/2019 - 09:40

Roughly a decade ago I read an article that asked antivirus vendors to stop intercepting encrypted HTTPS connections, this practice actively hurting security and privacy. As you can certainly imagine, antivirus vendors agreed with the sensible argument and today no reasonable antivirus product would even consider intercepting HTTPS traffic. Just kidding… Of course they kept going, and so two years ago a study was published detailing the security issues introduced by interception of HTTPS connections. Google and Mozilla once again urged antivirus vendors to stop. Surely this time it worked?

Of course not. So when I decided to look into Kaspersky Internet Security in December last year, I found it breaking up HTTPS connections so that it would get between the server and your browser in order to “protect” you. Expecting some deeply technical details about HTTPS protocol misimplementations now? Don’t worry, I don’t know enough myself to inspect Kaspersky software on this level. The vulnerabilities I found were far more mundane.

Kaspersky Internet Security getting between browser and server

I reported eight vulnerabilities to Kaspersky Lab between 2018-12-13 and 2018-12-21. This article will only describe three vulnerabilities which have been fixed in April this year. This includes two vulnerabilities that weren’t deemed a security risk by Kaspersky, it’s up to you to decide whether you agree with this assessment. The remaining five vulnerabilities have only been fixed in July, and I agreed to wait until November with the disclosure to give users enough time to upgrade.

Edit (2019-08-22): In order to disable this functionality you have to go into Settings, select “Additional” on the left side, then click “Network.” There you will see a section called “Encryption connection scanning” where you need to choose “Do not scan encrypted connections.”


The underappreciated certificate warning pages

There is an important edge case with HTTPS connections: what if a connection is established but the other side uses an invalid certificate? Current browsers will generally show you a certificate warning page in this scenario. In Firefox it looks like this:

Certificate warning page in Firefox

This page has seen a surprising amount of changes over the years. The browser vendors recognized that asking users to make a decision isn’t a good idea here. Most of the time, getting out is the best course of action, and ignoring the warning only a viable option for very technical users. So the text here is very clear, low on technical details, and the recommended solution is highlighted. The option to ignore the warning is well-hidden on the other hand, to prevent people from using it without understanding the implications. While the page looks different in other browsers, the main design considerations are the same.

But with Kaspersky Internet Security in the middle, the browser is no longer talking to the server, Kaspersky is. The way HTTPS is designed, it means that Kaspersky is responsible for validating the server’s certificate and producing a certificate warning page. And that’s what the certificate warning page looks like then:

Certificate warning page when Kaspersky is installed

There is a considerable amount of technical details here, supposedly to allow users to make an informed decision, but usually confusing them instead. Oh, and why does it list the URL as “”? That’s not what I typed into the address bar, it’s actually what this site claims to be (the name has been extracted from the site’s invalid certificate). That’s a tiny security issue here, wasn’t worth reporting however as this only affects sites accessed by IP address which should never be the case with HTTPS.

The bigger issue: what is the user supposed to do here? There is “leave this website” in the text, but experience shows that people usually won’t read when hitting a roadblock like this. And the highlighted action here is “I understand the risks and wish to continue” which is what most users can be expected to hit.

Using clickjacking to override certificate warnings

Let’s say that we hijacked some user’s web traffic, e.g. by tricking them into connecting to our malicious WiFi hotspot. Now we want to do something evil with that, such as collecting their Google searches or hijacking their Google account. Unfortunately, HTTPS won’t let us do it. If we place ourselves between the user and the Google server, we have to use our own certificate for the connection to the user. With our certificate being invalid, this will trigger a certificate warning however.

So the goal is to make the user click “I understand the risks and wish to continue” on the certificate warning page. We could just ask nicely, and given how this page is built we’ll probably succeed in a fair share of cases. Or we could use a trick called clickjacking – let the user click it without realizing what they are clicking.

There is only one complication. When the link is clicked there will be an additional confirmation pop-up:

Warning displayed by Kaspersky when overriding a certificate

But don’t despair just yet! That warning is merely generic text, it would apply to any remotely insecure action. We would only need to convince the user that the warning is expected and they will happily click “Continue.” For example, we could give them the following page when they first connect to the network, similar to those captive portals:

Fake Kaspersky warning page

Looks like a legitimate Kaspersky warning page but isn’t, the text here was written by me. The only “real” thing here is the “I understand the risks and wish to continue” link which actually belongs to an embedded frame. That frame contains Kaspersky’s certificate warning for and has been positioned in such a way that only the link is visible. When the user clicks it, they will get the generic warning from above and without doubt confirm ignoring the invalid certificate. We won, now we can do our evil thing without triggering any warnings!

How browser vendors deal with this kind of attack? They require at least two clicks to happen on different spots of the certificate warning page in order to add an exception for an invalid certificate, this makes clickjacking attacks impracticable. Kaspersky on the other hand felt very confident about their warning prompt, so they opted for adding more information to it. This message will now show you the name of the site you are adding the exception for. Let’s just hope that accessing a site by IP address is the only scenario where attackers can manipulate that name…

Something you probably don’t know about HSTS

There is a slightly less obvious detail to the attack described above: it shouldn’t have worked at all. See, if you reroute traffic to a malicious server and navigate to the site then, neither Firefox nor Chrome will give you the option to override the certificate warning. Getting out will be the only option available, meaning no way whatsoever to exploit the certificate warning page. What is this magic? Did browsers implement some special behavior only for Google?

Firefox certificate warning for

They didn’t. What you see here is a side-effect of the HTTP Strict-Transport-Security (HSTS) mechanism, which Google and many other websites happen to use. When you visit Google it will send the HTTP header Strict-Transport-Security: max-age=31536000 with the response. This tells the browser: “This is an HTTPS-only website, don’t ever try to create an unencrypted connection to it. Keep that in mind for the next year.”

So when the browser later encounters a certificate error on a site using HSTS, it knows: the website owner promised to keep HTTPS functional. There is no way that an invalid certificate is ok here, so allowing users to override the certificate would be wrong.

Unless you have Kaspersky in the middle of course, because Kaspersky completely ignores HSTS and still allows users to override the certificate. When I reported this issue, the vendor response was that this isn’t a security risk because the warning displayed is sufficient. Somehow they decided to add support for HSTS nevertheless, so that current versions will no longer allow overriding certificates here.

It’s no doubt that there are more scenarios where Kaspersky software weakens the security precautions made by browsers. For example, if a certificate is revoked (usually because it has been compromised), browsers will normally recognize that thanks to OCSP stapling and prevent the connection. But I noticed recently that Kaspersky Internet Security doesn’t support OCSP stapling, so if this application is active it will happily allow you to connect to a likely malicious server.

Using injected content for Universal XSS

Kaspersky Internet Security isn’t merely listening in on connections to HTTPS sites, it is also actively modifying those. In some cases it will generate a response of its own, such as the certificate warning page we saw above. In others it will modify the response sent by the server.

For example, if you didn’t install the Kaspersky browser extension, it will fall back to injecting a script into server responses which is then responsible for “protecting” you. This protection does things like showing a green checkmark next to Google search results that are considered safe. As Heise Online wrote merely a few days ago, this also used to leak a unique user ID which allowed tracking users regardless of any protective measures on their side. Oops…

There is a bit more to this feature called URL Advisor. When you put the mouse cursor above the checkmark icon a message appears stating that you have a safe site there. That message is a frame displaying url_advisor_balloon.html. Where does this file load from? If you have the Kaspersky browser extension, it will be part of that browser extension. If you don’t, it will load from in Firefox and in Chrome – Kaspersky software will intercept requests to these servers and answer them locally. I noticed however that things were different in Microsoft Edge, here this file would load directly from (or any other website if you changed the host name).

URL Advisor frame showing up when the checkmark icon is hovered

Certainly, when injecting their own web page into every domain on the web Kaspersky developers thought about making it very secure? Let’s have a look at the code running there:

var policeLink = document.createElement("a"); policeLink.href = IsDefined(UrlAdvisorLinkPoliceDecision) ? UrlAdvisorLinkPoliceDecision : locales["UrlAdvisorLinkPoliceDecision"]; = "_blank"; div.appendChild(policeLink);

This creates a link inside the frame dynamically. Where the link target comes from? It’s part of the data received from the parent document, no validation performed. In particular, javascript: links will be happily accepted. So a malicious website needs to figure out the location of url_advisor_balloon.html and embed it in a frame using the host name of the website they want to attack. Then they send a message to it:

frame.contentWindow.postMessage(JSON.stringify({ command: "init", data: { verdict: { url: "", categories: [ 21 ] }, locales: { UrlAdvisorLinkPoliceDecision: "javascript:alert('Hi, this JavaScript code is running on ' + document.domain)", CAT_21: "click here" } } }), "*");

What you get is a link labeled “click here” which will run arbitrary JavaScript code in the context of the attacked domain when clicked. And once again, the attackers could ask the user nicely to click it. Or they could use clickjacking, so whenever the user clicks anywhere on their site, the click goes to this link inside an invisible frame.

Injected JavaScript code running in context of the Google domain

And here you have it: a malicious website taking over your Google or social media accounts, all because Kaspersky considered it a good idea to have their content injected into secure traffic of other people’s domains. But at least this particular issue was limited to Microsoft Edge.

  • 2018-12-13: Sent report via Kaspersky bug bounty program: Lack of HSTS support facilitating MiTM attacks.
  • 2018-12-17: Sent reports via Kaspersky bug bounty program: Certificate warning pages susceptible to clickjacking and Universal XSS in Microsoft Edge.
  • 2018-12-20: Response from Kaspersky: HSTS and clickjacking reports are not considered security issues.
  • 2018-12-20: Requested disclosure of the HSTS and clickjacking reports.
  • 2018-12-24: Disclosure denied due to similarity with one of my other reports.
  • 2019-04-29: Kaspersky notifies me about the three issues here being fixed (KIS 2019 Patch E, actually released three weeks earlier).
  • 2019-04-29: Requested disclosure of these three issues, no response.
  • 2019-07-29: With five remaining issues reported by me fixed (KIS 2019 Patch F and KIS 2020), requested disclosure on all reports.
  • 2019-08-04: Disclosure denied on HSTS report because “You’ve requested too many tickets for disclosure at the same time.”
  • 2019-08-05: Disclosure denied on five not yet disclosed reports, asking for time until November for users to update.
  • 2019-08-06: Notified Kaspersky about my intention to publish an article about the three issues here on 2019-08-19, no response.
  • 2019-08-12: Reminded Kaspersky that I will publish an article on these three issues on 2019-08-19.
  • 2019-08-12: Kaspersky requesting an extension of the timeline until 2019-08-22, citing that they need more time to prepare.
  • 2019-08-16: Security advisory published by Kaspersky without notifying me.
Categorieën: Mozilla-nl planet

Cameron Kaiser: Chrome murders FTP like Jeffrey Epstein

Mozilla planet - za, 17/08/2019 - 16:36
What is it with these people? Why can't things that are working be allowed to still go on working? (Blah blah insecure blah blah unused blah blah maintenance blah blah web everything.)

This leaves an interesting situation where Google has, in its very own search index, HTML pages served by FTP its own browser won't be able to view:

At the top of the search results, even!

Obviously those FTP HTML pages load just fine in mainline Firefox, at least as of this writing, and of course TenFourFox. (UPDATE: This won't work in Firefox either after Fx70, though FTP in general will still be accessible. Note that it references Chrome's announcements; as usual, these kinds of distributed firing squads tend to be self-reinforcing.)

Is it a little ridiculous to serve pages that way? Okay, I'll buy that. But it works fine and wasn't bothering anyone, and they must have some relevance to be accessible because Google even indexed them.

Why is everything old suddenly so bad?

Categorieën: Mozilla-nl planet

Tantek Çelik: IndieWebCamps Timeline 2011-2019: Amsterdam to Utrecht

Mozilla planet - vr, 16/08/2019 - 23:21

While not a post directly about IndieWeb Summit 2019, this post provides a bit of background and is certainly related, so I’m including it in my series of posts about the Summit. Previous post in this series:

At the beginning of IndieWeb Summit 2019, I gave a brief talk on State of the IndieWeb and mentioned that:

We've scheduled lots of IndieWebCamps this year and are on track to schedule a record number of different cities as well.

I had conceived of a graphical representation of the growth of IndieWebCamps over the past nine years, both in number and across the world, but with everything else involved with setting up and running the Summit, ran out of time. However, the idea persisted, and finally this past week, with a little help from Aaron Parecki re-implementing Dopplr’s algorithm for turning city names into colors, was able to put togther something pretty close to what I’d envisioned:

Istanbul  Amsterdam  Utrecht  Nürnberg    Düsseldorf      Berlin      Edinburgh  Oxford   Brighton       New Haven  Baltimore  Cambridge    New York      Austin   Bellingham  Los Angeles   San Francisco    Portland          201120122013201420152016201720182019

I don’t know of any tools to take something like this kind of locations vs years data and graph it as such. So I built an HTML table with a cell for each IndieWebCamp, as well as cells for the colspans of empty space. Each colored cell is hyperlinked to the IndieWebCamp for that city for that year.

2011-2018 and over half of 2019 are IndieWebCamps (and Summits) that have already happened. 2019 includes bars for four upcoming IndieWebCamps, which are fully scheduled and open for sign-ups.

The table markup is copy pasted from the IndieWebCamp wiki template where I built it, and you can see the template working live in the context of the IndieWebCamp Cities page. I’m sure the markup could be improved, suggestions welcome!

Categorieën: Mozilla-nl planet

Rumbling Edge - Thunderbird: 2015-05-26 Calendar builds

Thunderbird - wo, 27/05/2015 - 10:26

Common (excluding Website bugs)-specific: (23)

  • Fixed: 735253 – JavaScript Error: “TypeError: calendar is null” {file: “chrome://calendar/content/calendar-task-editing.js” line: 102}
  • Fixed: 768207 – Make the cache checkbox default-on in the new calendar dialog
  • Fixed: 1049591 – Fix lots of strict warnings
  • Fixed: 1086573 – Lightning and Thunderbird disagree about timezone support in ics files
  • Fixed: 1099592 – Make JS callers of ios.newChannel call ios.newChannel2 in calendar/
  • Fixed: 1149423 – Add Windows timezone names to list of aliases
  • Fixed: 1151011 – Calendar events show up on wrong day when printing
  • Fixed: 1151440 – Choose a color not responsive when creating a New calendar in Lightning 4.0b1
  • Fixed: 1153327 – Run compare-locales with merging for Lightning
  • Fixed: 1156015 – Email scheduling fails for recipients with URN id
  • Fixed: 1158036 – Support sendMailTo for URN type attendees
  • Fixed: 1159447 – TEST-UNEXPECTED-FAIL | xpcshell-icaljs.ini:calendar/test/unit/test_extract.js
  • Fixed: 1159638 – Getter fails in calender-migration-dialog on first run after installation
  • Fixed: 1159682 – Provide a more appropriate “learn more” page on integrated Lightning firstrun
  • Fixed: 1159698 – Opt-out dialog has a button for “disable”, but actually the addon is removed
  • Fixed: 1160728 – Unbreak Lightning 4.0b4 beta builds
  • Fixed: 1162300 – TEST-UNEXPECTED-FAIL | xpcshell-libical.ini:calendar/test/unit/test_alarm.js | xpcshell return code: 0
  • Fixed: 1163306 – Re-enable libical tests and disable ical.js in nightly builds when binary compatibility is back
  • Fixed: 1165002 – Lightning broken, tries to load libical backend although “calendar.icaljs” defaults to “true”
  • Fixed: 1165315 – TEST-UNEXPECTED-FAIL | xpcshell-icaljs.ini:calendar/test/unit/test_bug759324.js | xpcshell return code: 1 | ###!!! ASSERTION: Deprecated, use NewChannelFromURI2 providing loadInfo arguments!
  • Fixed: 1165497 – TEST-UNEXPECTED-FAIL | xpcshell-icaljs.ini:calendar/test/unit/test_alarmservice.js | xpcshell return code: -11
  • Fixed: 1165726 – TEST-UNEXPECTED-FAIL | /builds/slave/test/build/tests/mozmill/testBasicFunctionality.js | testBasicFunctionality.js::testSmokeTest
  • Fixed: 1165728 – TEST-UNEXPECTED-FAIL | xpcshell-icaljs.ini:calendar/test/unit/test_bug494140.js | xpcshell return code: -11

Sunbird will no longer be actively developed by the Calendar team.

Windows builds Official Windows

Linux builds Official Linux (i686), Official Linux (x86_64)

Mac builds Official Mac

Categorieën: Mozilla-nl planet

Rumbling Edge - Thunderbird: 2015-05-26 Thunderbird comm-central builds

Thunderbird - wo, 27/05/2015 - 10:25

Thunderbird-specific: (54)

  • Fixed: 401779 – Integrate Lightning Into Thunderbird by Default and Ship Thunderbird with Lightning Enabled
  • Fixed: 717292 – Spell check language setting for subject and body not synchronized, but temporarily appears so when changing language and depending on focus (confusing ux)
  • Fixed: 914225 – Support hotfix add-on in Thunderbird
  • Fixed: 1025547 – newmailaccount/jquery.tmpl.js, line 123: reference to undefined property def[1]
  • Fixed: 1088975 – Answering mail with sendername containing encoded special chars and comma creates two “To”-entries
  • Fixed: 1101237 – Remove distribution directory during install
  • Fixed: 1109178 – Thunderbird OAuth implementation does not work with Evernote
  • Fixed: 1110166 – Port |Bug 1102219 – Rename String.prototype.contains to String.prototype.includes| to comm-central
  • Fixed: 1113097 – Fix misuse of fixIterator
  • Fixed: 1130854 – Package Lightning with Thunderbird
  • Fixed: 1131997 – Adapt for Debugger Server code for changes in bug 1059308
  • Fixed: 1135291 – Update chat log entries added to Gloda since bug 955292 to use relative paths
  • Fixed: 1135588 – New conversations get indexed twice by gloda, leading to duplicate search results
  • Fixed: 1138154 – Plugins default to “always activate” in Thunderbird
  • Fixed: 1142879 – [meta] track Mozilla-central (Core) issues that we want to have fixed in TB38
  • Fixed: 1146698 – Chat Messages added to logs just before shutdown may not be indexed by gloda
  • Fixed: 1148330 – Font indicator doesn’t update when cursor is placed in text where core returns sans-serif (Windows). Serif and monospace don’t work (Linux).
  • Fixed: 1148512 – TEST-UNEXPECTED-FAIL | mailnews/imap/test/unit/test_dod.js | xpcshell return code: 0||1 | streamMessages – [streamMessages : 94] false == true | application crashed [@ mozalloc_abort(char const * const)]
  • Fixed: 1149059 – splitter in compose window can be resized down to completely obscure composition area
  • Fixed: 1151206 – Using a theme hides minimize, maximize and close button in composer window [Mac]
  • Fixed: 1151475 – Remove use of expression closures in mail/
  • Fixed: 1152299 – [autoconfig] Cosmetic changes for WEB.DE config
  • Fixed: 1152706 – Upgrade to Correspondents column (combined To/From column) too agressive
  • Fixed: 1152796 – chrome://messenger/content/folderDisplay.js, line 697: TypeError: this._savedColumnStates.correspondentCol is undefined
  • Fixed: 1152926 – New mail sound preview doesn’t work for default system sound on Mac OS X
  • Fixed: 1154737 – Permafail: TEST-UNEXPECTED-FAIL | toolkit/components/telemetry/tests/unit/test_TelemetryPing.js | xpcshell return code: 0
  • Fixed: 1154747 – TEST-UNEXPECTED-FAIL | /builds/slave/test/build/tests/mozmill/session-store/test-session-store.js | test-session-store.js::test_message_pane_height_persistence
  • Fixed: 1156669 – Trash folder duplication while using IMAP with localized TB
  • Fixed: 1157236 – In-content dialogs: Port bug 1043612, bug 1148923 and bug 1141031 to TB
  • Fixed: 1157649 – TEST-UNEXPECTED-FAIL | dom/push/test/xpcshell/test_clearAll_successful.js (and most other push tests)
  • Fixed: 1158824 – Port bug 138009 to fix packaging errors | Missing file(s): bin/defaults/autoconfig/platform.js
  • Fixed: 1159448 – Thunderbird ignores proxy settings on POP3S protocol
  • Fixed: 1159627 – resource:///modules/dbViewWrapper.js, line 560: SyntaxError: unreachable code after return statement
  • Fixed: 1159630 – components/glautocomp.js, line 155: SyntaxError: unreachable code after return statement
  • Fixed: 1159676 – mailnews/mime/jsmime/test/test_custom_headers.js | run_next_test 0 – TypeError: _gRunningTest is undefined at /builds/slave/test/build/tests/xpcshell/head.js:1435 (and other jsmime tests)
  • Fixed: 1159688 – After switching/changing the window layout, dragging the splitter between threadpane and messagepane can create gray/grey area/space (misplaced notificationbox)
  • Fixed: 1159815 – Take bug 1154791 “Inline spell checker loses red underlines after a backspace is used – take two” in Thunderbird 38
  • Fixed: 1159817 – Take “Bug 1100966 – Inline spell checker loses red underlines after a backspace is used” in Thunderbird 38
  • Fixed: 1159834 – Consider taking “Bug 756984 – Changing location in editor doesn’t preserve the font when returning to end of text/line” in Thunderbird 38
  • Fixed: 1159923 – Take bug 1140105 “Can’t query for a specific font face when the selection is collapsed” in TB 38
  • Fixed: 1160105 – Fix strict mode warnings in protovis-r2.6-modded.js
  • Fixed: 1160106 – “Searching…” spinner at the bottom of gloda search results never goes away
  • Fixed: 1160114 – Strict mode warnings on faceted search
  • Fixed: 1160805 – Missing Windows and Linux nightly builds, build step set props: previous_buildid fails
  • Fixed: 1161162 – “Join Chat” doesn’t focus the newly joined MUC
  • Fixed: 1162396 – Take bug 1140617 “Pasting an image loses the composition style” in TB38
  • Fixed: 1163086 – Take bug 967494 “changing spellcheck language in one composition window affects all open and new compositions” in TB38
  • Fixed: 1163299 – “TypeError: getBrowser(…) is null” in contentAreaClick with Lightning installed and started in calendar view
  • Fixed: 1163343 – Incorrectly formatted error message “sending failed”
  • Fixed: 1164415 – Error in comment for imapEnterServerPasswordPrompt
  • Fixed: 1164658 – TypeError: Cc[‘;1’] is undefined at resource://gre/modules/FxAccountsWebChannel.jsm:227
  • Fixed: 1164707 – missing toolkit_perfmonitoring.xpt in aurora builds
  • Fixed: 1165152 – Take bug 1154894 in TB 38 branch: Disable test_plugin_default_state.js so Thunderbird can ship with plugins disabled by default
  • Fixed: 1165320 – TEST-UNEXPECTED-FAIL | /builds/slave/test/build/tests/mozmill/notification/test-notification.js

MailNews Core-specific: (30)

  • Fixed: 610533 – crash [@ nsMsgDatabase::GetSearchResultsTable(char const*, int, nsIMdbTable**)] with virtual folder
  • Fixed: 745664 – Rename Address book aaa to aaa_test, delete another address book bbb, and renamed address book aaa_test will lose its name and appear deleted after restart (dataloss! involving localized names)
  • Fixed: 777770 – get rid of nsVoidArray from /mailnews
  • Fixed: 786141 – Use nsIFile.exists() instead of stat to check the existence of the file
  • Fixed: 1069790 – Email addresses with parenthesis are not pretty-printed anymore
  • Fixed: 1072611 – Ctrl+P not working from Composition’s Print Preview window
  • Fixed: 1099587 – Make JS callers of ios.newChannel call ios.newChannel2 in mail/ and mailnews/
  • Fixed: 1130248 – |To: “” <>| becomes |”foo@example.comfoo”| when I compose mail to it
  • Fixed: 1138220 – some headers are not not properly capitalized
  • Fixed: 1141446 – Behaviour of malformed rfc2047 encoded From message header inconsistent
  • Fixed: 1143569 – User-agent error when posting to NNTP due to RFC5536 violation of Tb (user-agent header is folded just after user-agent:, “user-agent:[CRLF][SP]Mozilla…”)
  • Fixed: 1144693 – Disable libnotify usage on Linux by default for new-mail notifications (doesn’t always work after bug 858919)
  • Fixed: 1149320 – fix compile warnings in mailnews/extensions/
  • Fixed: 1150891 – Port changes from Bug 1115495 – Part 2: PAC generator for browsing and system wide proxy
  • Fixed: 1151782 – Inputting 29th Feb as a birthday in the addressbook contact replaces it with 1st Mar.
  • Fixed: 1152364 – crash in Address Book via nsAbBSDirectory::GetChildNodes nsCOMArrayEnumerator::operator new(unsigned int, nsCOMArray_base const&)
  • Fixed: 1152989 – Account Manager Extensions broken in Thunderbird 37/38
  • Fixed: 1154521 – jsmime fails on long references header and e-mail gets sent and stored in Sent without headers
  • Fixed: 1155491 – Support autoconfig and manual config of gmail IMAP OAuth2 authentication
  • Fixed: 1155952 – Nesting level does not match indentation
  • Fixed: 1156691 – GUI “Edit filters”: Conditions/actions (for specfic accounts) not visible
  • Fixed: 1156777 – nsParseMailbox.cpp:505:55: error: ‘do_QueryObject’ was not declared in this scope
  • Fixed: 1158501 – Port bug 1039866 (metro code removal) and bug 1085557 (addition of socorro symbol upload API)
  • Fixed: 1158751 – Port NO_JS_MANIFEST changes | mozbuild.frontend.reader.SandboxValidationError: calendar/base/backend/icaljs/
  • Fixed: 1159255 – Build error: MSVC_ENABLE_PGO = True is not permitted to be used in mailnews/intl/
  • Fixed: 1159626 – chrome://messenger/content/accountUtils.js, line 455: SyntaxError: unreachable code after return statement
  • Fixed: 1160647 – Port |Bug 1159972 – Remove the fallible version of PL_DHashTableInit()| to comm-central
  • Fixed: 1163347 – Don’t require scope in ispdb config for OAuth2
  • Fixed: 1165737 – Fix usage of NS_LITERAL_CSTRING in mailnews, port Bug 1155963 to comm-central
  • Fixed: 1166842 – Re-enable binary extensions for comm-central

Windows builds Official Windows, Official Windows installer

Linux builds Official Linux (i686), Official Linux (x86_64)

Mac builds Official Mac

Categorieën: Mozilla-nl planet

Andrew Sutherland: Talk Script: Firefox OS Email Performance Strategies

Thunderbird - do, 30/04/2015 - 22:11

Last week I gave a talk at the Philly Tech Week 2015 Dev Day organized by the delightful people at on some of the tricks/strategies we use in the Firefox OS Gaia Email app.  Note that the credit for implementing most of these techniques goes to the owner of the Email app’s front-end, James Burke.  Also, a special shout-out to Vivien for the initial DOM Worker patches for the email app.

I tried to avoid having slides that both I would be reading aloud as the audience read silently, so instead of slides to share, I have the talk script.  Well, I also have the slides here, but there’s not much to them.  The headings below are the content of the slides, except for the one time I inline some code.  Note that the live presentation must have differed slightly, because I’m sure I’m much more witty and clever in person than this script would make it seem…

Cover Slide: Who!

Hi, my name is Andrew Sutherland.  I work at Mozilla on the Firefox OS Email Application.  I’m here to share some strategies we used to make our HTML5 app Seem faster and sometimes actually Be faster.

What’s A Firefox OS (Screenshot Slide)

But first: What is a Firefox OS?  It’s a multiprocess Firefox gecko engine on an android linux kernel where all the apps including the system UI are implemented using HTML5, CSS, and JavaScript.  All the apps use some combination of standard web APIs and APIs that we hope to standardize in some form.

Firefox OS homescreen screenshot Firefox OS clock app screenshot Firefox OS email app screenshot

Here are some screenshots.  We’ve got the default home screen app, the clock app, and of course, the email app.

It’s an entirely client-side offline email application, supporting IMAP4, POP3, and ActiveSync.  The goal, like all Firefox OS apps shipped with the phone, is to give native apps on other platforms a run for their money.

And that begins with starting up fast.

Fast Startup: The Problems

But that’s frequently easier said than done.  Slow-loading websites are still very much a thing.

The good news for the email application is that a slow network isn’t one of its problems.  It’s pre-loaded on the phone.  And even if it wasn’t, because of the security implications of the TCP Web API and the difficulty of explaining this risk to users in a way they won’t just click through, any TCP-using app needs to be a cryptographically signed zip file approved by a marketplace.  So we do load directly from flash.

However, it’s not like flash on cellphones is equivalent to an infinitely fast, zero-latency network connection.  And even if it was, in a naive app you’d still try and load all of your HTML, CSS, and JavaScript at the same time because the HTML file would reference them all.  And that adds up.

It adds up in the form of event loop activity and competition with other threads and processes.  With the exception of Promises which get their own micro-task queue fast-lane, the web execution model is the same as all other UI event loops; events get scheduled and then executed in the same order they are scheduled.  Loading data from an asynchronous API like IndexedDB means that your read result gets in line behind everything else that’s scheduled.  And in the case of the bulk of shipped Firefox OS devices, we only have a single processor core so the thread and process contention do come into play.

So we try not to be a naive.

Seeming Fast at Startup: The HTML Cache

If we’re going to optimize startup, it’s good to start with what the user sees.  Once an account exists for the email app, at startup we display the default account’s inbox folder.

What is the least amount of work that we can do to show that?  Cache a screenshot of the Inbox.  The problem with that, of course, is that a static screenshot is indistinguishable from an unresponsive application.

So we did the next best thing, (which is) we cache the actual HTML we display.  At startup we load a minimal HTML file, our concatenated CSS, and just enough Javascript to figure out if we should use the HTML cache and then actually use it if appropriate.  It’s not always appropriate, like if our application is being triggered to display a compose UI or from a new mail notification that wants to show a specific message or a different folder.  But this is a decision we can make synchronously so it doesn’t slow us down.

Local Storage: Okay in small doses

We implement this by storing the HTML in localStorage.

Important Disclaimer!  LocalStorage is a bad API.  It’s a bad API because it’s synchronous.  You can read any value stored in it at any time, without waiting for a callback.  Which means if the data is not in memory the browser needs to block its event loop or spin a nested event loop until the data has been read from disk.  Browsers avoid this now by trying to preload the Entire contents of local storage for your origin into memory as soon as they know your page is being loaded.  And then they keep that information, ALL of it, in memory until your page is gone.

So if you store a megabyte of data in local storage, that’s a megabyte of data that needs to be loaded in its entirety before you can use any of it, and that hangs around in scarce phone memory.

To really make the point: do not use local storage, at least not directly.  Use a library like localForage that will use IndexedDB when available, and then fails over to WebSQLDatabase and local storage in that order.

Now, having sufficiently warned you of the terrible evils of local storage, I can say with a sorta-clear conscience… there are upsides in this very specific case.

The synchronous nature of the API means that once we get our turn in the event loop we can act immediately.  There’s no waiting around for an IndexedDB read result to gets its turn on the event loop.

This matters because although the concept of loading is simple from a User Experience perspective, there’s no standard to back it up right now.  Firefox OS’s UX desires are very straightforward.  When you tap on an app, we zoom it in.  Until the app is loaded we display the app’s icon in the center of the screen.  Unfortunately the standards are still assuming that the content is right there in the HTML.  This works well for document-based web pages or server-powered web apps where the contents of the page are baked in.  They work less well for client-only web apps where the content lives in a database and has to be dynamically retrieved.

The two events that exist are:

DOMContentLoaded” fires when the document has been fully parsed and all scripts not tagged as “async” have run.  If there were stylesheets referenced prior to the script tags, the script tags will wait for the stylesheet loads.

load” fires when the document has been fully loaded; stylesheets, images, everything.

But none of these have anything to do with the content in the page saying it’s actually done.  This matters because these standards also say nothing about IndexedDB reads or the like.  We tried to create a standards consensus around this, but it’s not there yet.  So Firefox OS just uses the “load” event to decide an app or page has finished loading and it can stop showing your app icon.  This largely avoids the dreaded “flash of unstyled content” problem, but it also means that your webpage or app needs to deal with this period of time by displaying a loading UI or just accepting a potentially awkward transient UI state.

(Trivial HTML slide)

<link rel=”stylesheet” ...> <script ...></script> DOMContentLoaded!

This is the important summary of our index.html.

We reference our stylesheet first.  It includes all of our styles.  We never dynamically load stylesheets because that compels a style recalculation for all nodes and potentially a reflow.  We would have to have an awful lot of style declarations before considering that.

Then we have our single script file.  Because the stylesheet precedes the script, our script will not execute until the stylesheet has been loaded.  Then our script runs and we synchronously insert our HTML from local storage.  Then DOMContentLoaded can fire.  At this point the layout engine has enough information to perform a style recalculation and determine what CSS-referenced image resources need to be loaded for buttons and icons, then those load, and then we’re good to be displayed as the “load” event can fire.

After that, we’re displaying an interactive-ish HTML document.  You can scroll, you can press on buttons and the :active state will apply.  So things seem real.

Being Fast: Lazy Loading and Optimized Layers

But now we need to try and get some logic in place as quickly as possible that will actually cash the checks that real-looking HTML UI is writing.  And the key to that is only loading what you need when you need it, and trying to get it to load as quickly as possible.

There are many module loading and build optimizing tools out there, and most frameworks have a preferred or required way of handling this.  We used the RequireJS family of Asynchronous Module Definition loaders, specifically the alameda loader and the r-dot-js optimizer.

One of the niceties of the loader plugin model is that we are able to express resource dependencies as well as code dependencies.

RequireJS Loader Plugins

var fooModule = require('./foo'); var htmlString = require('text!./foo.html'); var localizedDomNode = require('tmpl!./foo.html');

The standard Common JS loader semantics used by node.js and io.js are the first one you see here.  Load the module, return its exports.

But RequireJS loader plugins also allow us to do things like the second line where the exclamation point indicates that the load should occur using a loader plugin, which is itself a module that conforms to the loader plugin contract.  In this case it’s saying load the file foo.html as raw text and return it as a string.

But, wait, there’s more!  loader plugins can do more than that.  The third example uses a loader that loads the HTML file using the ‘text’ plugin under the hood, creates an HTML document fragment, and pre-localizes it using our localization library.  And this works un-optimized in a browser, no compilation step needed, but it can also be optimized.

So when our optimizer runs, it bundles up the core modules we use, plus, the modules for our “message list” card that displays the inbox.  And the message list card loads its HTML snippets using the template loader plugin.  The r-dot-js optimizer then locates these dependencies and the loader plugins also have optimizer logic that results in the HTML strings being inlined in the resulting optimized file.  So there’s just one single javascript file to load with no extra HTML file dependencies or other loads.

We then also run the optimizer against our other important cards like the “compose” card and the “message reader” card.  We don’t do this for all cards because it can be hard to carve up the module dependency graph for optimization without starting to run into cases of overlap where many optimized files redundantly include files loaded by other optimized files.

Plus, we have another trick up our sleeve:

Seeming Fast: Preloading

Preloading.  Our cards optionally know the other cards they can load.  So once we display a card, we can kick off a preload of the cards that might potentially be displayed.  For example, the message list card can trigger the compose card and the message reader card, so we can trigger a preload of both of those.

But we don’t go overboard with preloading in the frontend because we still haven’t actually loaded the back-end that actually does all the emaily email stuff.  The back-end is also chopped up into optimized layers along account type lines and online/offline needs, but the main optimized JS file still weighs in at something like 17 thousand lines of code with newlines retained.

So once our UI logic is loaded, it’s time to kick-off loading the back-end.  And in order to avoid impacting the responsiveness of the UI both while it loads and when we’re doing steady-state processing, we run it in a DOM Worker.

Being Responsive: Workers and SharedWorkers

DOM Workers are background JS threads that lack access to the page’s DOM, communicating with their owning page via message passing with postMessage.  Normal workers are owned by a single page.  SharedWorkers can be accessed via multiple pages from the same document origin.

By doing this, we stay out of the way of the main thread.  This is getting less important as browser engines support Asynchronous Panning & Zooming or “APZ” with hardware-accelerated composition, tile-based rendering, and all that good stuff.  (Some might even call it magic.)

When Firefox OS started, we didn’t have APZ, so any main-thread logic had the serious potential to result in janky scrolling and the impossibility of rendering at 60 frames per second.  It’s a lot easier to get 60 frames-per-second now, but even asynchronous pan and zoom potentially has to wait on dispatching an event to the main thread to figure out if the user’s tap is going to be consumed by app logic and preventDefault called on it.  APZ does this because it needs to know whether it should start scrolling or not.

And speaking of 60 frames-per-second…

Being Fast: Virtual List Widgets

…the heart of a mail application is the message list.  The expected UX is to be able to fling your way through the entire list of what the email app knows about and see the messages there, just like you would on a native app.

This is admittedly one of the areas where native apps have it easier.  There are usually list widgets that explicitly have a contract that says they request data on an as-needed basis.  They potentially even include data bindings so you can just point them at a data-store.

But HTML doesn’t yet have a concept of instantiate-on-demand for the DOM, although it’s being discussed by Firefox layout engine developers.  For app purposes, the DOM is a scene graph.  An extremely capable scene graph that can handle huge documents, but there are footguns and it’s arguably better to err on the side of fewer DOM nodes.

So what the email app does is we create a scroll-region div and explicitly size it based on the number of messages in the mail folder we’re displaying.  We create and render enough message summary nodes to cover the current screen, 3 screens worth of messages in the direction we’re scrolling, and then we also retain up to 3 screens worth in the direction we scrolled from.  We also pre-fetch 2 more screens worth of messages from the database.  These constants were arrived at experimentally on prototype devices.

We listen to “scroll” events and issue database requests and move DOM nodes around and update them as the user scrolls.  For any potentially jarring or expensive transitions such as coordinate space changes from new messages being added above the current scroll position, we wait for scrolling to stop.

Nodes are absolutely positioned within the scroll area using their ‘top’ style but translation transforms also work.  We remove nodes from the DOM, then update their position and their state before re-appending them.  We do this because the browser APZ logic tries to be clever and figure out how to create an efficient series of layers so that it can pre-paint as much of the DOM as possible in graphic buffers, AKA layers, that can be efficiently composited by the GPU.  Its goal is that when the user is scrolling, or something is being animated, that it can just move the layers around the screen or adjust their opacity or other transforms without having to ask the layout engine to re-render portions of the DOM.

When our message elements are added to the DOM with an already-initialized absolute position, the APZ logic lumps them together as something it can paint in a single layer along with the other elements in the scrolling region.  But if we start moving them around while they’re still in the DOM, the layerization logic decides that they might want to independently move around more in the future and so each message item ends up in its own layer.  This slows things down.  But by removing them and re-adding them it sees them as new with static positions and decides that it can lump them all together in a single layer.  Really, we could just create new DOM nodes, but we produce slightly less garbage this way and in the event there’s a bug, it’s nicer to mess up with 30 DOM nodes displayed incorrectly rather than 3 million.

But as neat as the layerization stuff is to know about on its own, I really mention it to underscore 2 suggestions:

1, Use a library when possible.  Getting on and staying on APZ fast-paths is not trivial, especially across browser engines.  So it’s a very good idea to use a library rather than rolling your own.

2, Use developer tools.  APZ is tricky to reason about and even the developers who write the Async pan & zoom logic can be surprised by what happens in complex real-world situations.  And there ARE developer tools available that help you avoid needing to reason about this.  Firefox OS has easy on-device developer tools that can help diagnose what’s going on or at least help tell you whether you’re making things faster or slower:

– it’s got a frames-per-second overlay; you do need to scroll like mad to get the system to want to render 60 frames-per-second, but it makes it clear what the net result is

– it has paint flashing that overlays random colors every time it paints the DOM into a layer.  If the screen is flashing like a discotheque or has a lot of smeared rainbows, you know something’s wrong because the APZ logic is not able to to just reuse its layers.

– devtools can enable drawing cool colored borders around the layers APZ has created so you can see if layerization is doing something crazy

There’s also fancier and more complicated tools in Firefox and other browsers like Google Chrome to let you see what got painted, what the layer tree looks like, et cetera.

And that’s my spiel.


The source code to Gaia can be found at

The email app in particular can be found at

(I also asked for questions here.)

Categorieën: Mozilla-nl planet

Joshua Cranmer: Breaking news

Thunderbird - wo, 01/04/2015 - 09:00
It was brought to my attention recently by reputable sources that the recent announcement of increased usage in recent years produced an internal firestorm within Mozilla. Key figures raised alarm that some of the tech press had interpreted the blog post as a sign that Thunderbird was not, in fact, dead. As a result, they asked Thunderbird community members to make corrections to emphasize that Mozilla was trying to kill Thunderbird.

The primary fear, it seems, is that knowledge that the largest open-source email client was still receiving regular updates would impel its userbase to agitate for increased funding and maintenance of the client to help forestall potential threats to the open nature of email as well as to innovate in the space of providing usable and private communication channels. Such funding, however, would be an unaffordable luxury and would only distract Mozilla from its central goal of building developer productivity tooling. Persistent rumors that Mozilla would be willing to fund Thunderbird were it renamed Firefox Email were finally addressed with the comment, "such a renaming would violate our current policy that all projects be named Persona."

Categorieën: Mozilla-nl planet

Joshua Cranmer: Why email is hard, part 8: why email security failed

Thunderbird - di, 13/01/2015 - 05:38
This post is part 8 of an intermittent series exploring the difficulties of writing an email client. Part 1 describes a brief history of the infrastructure. Part 2 discusses internationalization. Part 3 discusses MIME. Part 4 discusses email addresses. Part 5 discusses the more general problem of email headers. Part 6 discusses how email security works in practice. Part 7 discusses the problem of trust. This part discusses why email security has largely failed.

At the end of the last part in this series, I posed the question, "Which email security protocol is most popular?" The answer to the question is actually neither S/MIME nor PGP, but a third protocol, DKIM. I haven't brought up DKIM until now because DKIM doesn't try to secure email in the same vein as S/MIME or PGP, but I still consider it relevant to discussing email security.

Unquestionably, DKIM is the only security protocol for email that can be considered successful. There are perhaps 4 billion active email addresses [1]. Of these, about 1-2 billion use DKIM. In contrast, S/MIME can count a few million users, and PGP at best a few hundred thousand. No other security protocols have really caught on past these three. Why did DKIM succeed where the others fail?

DKIM's success stems from its relatively narrow focus. It is nothing more than a cryptographic signature of the message body and a smattering of headers, and is itself stuck in the DKIM-Signature header. It is meant to be applied to messages only on outgoing servers and read and processed at the recipient mail server—it completely bypasses clients. That it bypasses clients allows it to solve the problem of key discovery and key management very easily (public keys are stored in DNS, which is already a key part of mail delivery), and its role in spam filtering is strong motivation to get it implemented quickly (it is 7 years old as of this writing). It's also simple: this one paragraph description is basically all you need to know [2].

The failure of S/MIME and PGP to see large deployment is certainly a large topic of discussion on myriads of cryptography enthusiast mailing lists, which often like to partake in propositions of new end-to-end encryption of email paradigms, such as the recent DIME proposal. Quite frankly, all of these solutions suffer broadly from at least the same 5 fundamental weaknesses, and I see it unlikely that a protocol will come about that can fix these weaknesses well enough to become successful.

The first weakness, and one I've harped about many times already, is UI. Most email security UI is abysmal and generally at best usable only by enthusiasts. At least some of this is endemic to security: while it mean seem obvious how to convey what an email signature or an encrypted email signifies, how do you convey the distinctions between sign-and-encrypt, encrypt-and-sign, or an S/MIME triple wrap? The Web of Trust model used by PGP (and many other proposals) is even worse, in that inherently requires users to do other actions out-of-band of email to work properly.

Trust is the second weakness. Consider that, for all intents and purposes, the email address is the unique identifier on the Internet. By extension, that implies that a lot of services are ultimately predicated on the notion that the ability to receive and respond to an email is a sufficient means to identify an individual. However, the entire purpose of secure email, or at least of end-to-end encryption, is subtly based on the fact that other people in fact have access to your mailbox, thus destroying the most natural ways to build trust models on the Internet. The quest for anonymity or privacy also renders untenable many other plausible ways to establish trust (e.g., phone verification or government-issued ID cards).

Key discovery is another weakness, although it's arguably the easiest one to solve. If you try to keep discovery independent of trust, the problem of key discovery is merely picking a protocol to publish and another one to find keys. Some of these already exist: PGP key servers, for example, or using DANE to publish S/MIME or PGP keys.

Key management, on the other hand, is a more troubling weakness. S/MIME, for example, basically works without issue if you have a certificate, but managing to get an S/MIME certificate is a daunting task (necessitated, in part, by its trust model—see how these issues all intertwine?). This is also where it's easy to say that webmail is an unsolvable problem, but on further reflection, I'm not sure I agree with that statement anymore. One solution is just storing the private key with the webmail provider (you're trusting them as an email client, after all), but it's also not impossible to imagine using phones or flash drives as keystores. Other key management factors are more difficult to solve: people who lose their private keys or key rollover create thorny issues. There is also the difficulty of managing user expectations: if I forget my password to most sites (even my email provider), I can usually get it reset somehow, but when a private key is lost, the user is totally and completely out of luck.

Of course, there is one glaring and almost completely insurmountable problem. Encrypted email fundamentally precludes certain features that we have come to take for granted. The lesser known is server-side search and filtration. While there exist some mechanisms to do search on encrypted text, those mechanisms rely on the fact that you can manipulate the text to change the message, destroying the integrity feature of secure email. They also tend to be fairly expensive. It's easy to just say "who needs server-side stuff?", but the contingent of people who do email on smartphones would not be happy to have to pay the transfer rates to download all the messages in their folder just to find one little email, nor the energy costs of doing it on the phone. And those who have really large folders—Fastmail has a design point of 1,000,000 in a single folder—would still prefer to not have to transfer all their mail even on desktops.

The more well-known feature that would disappear is spam filtration. Consider that 90% of all email is spam, and if you think your spam folder is too slim for that to be true, it's because your spam folder only contains messages that your email provider wasn't sure were spam. The loss of server-side spam filtering would dramatically increase the cost of spam (a 10% reduction in efficiency would double the amount of server storage, per my calculations), and client-side spam filtering is quite literally too slow [3] and too costly (remember smartphones? Imagine having your email take 10 times as much energy and bandwidth) to be a tenable option. And privacy or anonymity tends to be an invitation to abuse (cf. Tor and Wikipedia). Proposed solutions to the spam problem are so common that there is a checklist containing most of the objections.

When you consider all of those weaknesses, it is easy to be pessimistic about the possibility of wide deployment of powerful email security solutions. The strongest future—all email is encrypted, including metadata—is probably impossible or at least woefully impractical. That said, if you weaken some of the assumptions (say, don't desire all or most traffic to be encrypted), then solutions seem possible if difficult.

This concludes my discussion of email security, at least until things change for the better. I don't have a topic for the next part in this series picked out (this part actually concludes the set I knew I wanted to discuss when I started), although OAuth and DMARC are two topics that have been bugging me enough recently to consider writing about. They also have the unfortunate side effect of being things likely to see changes in the near future, unlike most of the topics I've discussed so far. But rest assured that I will find more difficulties in the email infrastructure to write about before long!

[1] All of these numbers are crude estimates and are accurate to only an order of magnitude. To justify my choices: I assume 1 email address per Internet user (this overestimates the developing world and underestimates the developed world). The largest webmail providers have given numbers that claim to be 1 billion active accounts between them, and all of them use DKIM. S/MIME is guessed by assuming that any smartcard deployment supports S/MIME, and noting that the US Department of Defense and Estonia's digital ID project are both heavy users of such smartcards. PGP is estimated from the size of the strong set and old numbers on the reachable set from the core Web of Trust.
[2] Ever since last April, it's become impossible to mention DKIM without referring to DMARC, as a result of Yahoo's controversial DMARC policy. A proper discussion of DMARC (and why what Yahoo did was controversial) requires explaining the mail transmission architecture and spam, however, so I'll defer that to a later post. It's also possible that changes in this space could happen within the next year.
[3] According to a former GMail spam employee, if it takes you as long as three minutes to calculate reputation, the spammer wins.

Categorieën: Mozilla-nl planet

Joshua Cranmer: A unified history for comm-central

Thunderbird - za, 10/01/2015 - 18:55
Several years back, Ehsan and Jeff Muizelaar attempted to build a unified history of mozilla-central across the Mercurial era and the CVS era. Their result is now used in the gecko-dev repository. While being distracted on yet another side project, I thought that I might want to do the same for comm-central. It turns out that building a unified history for comm-central makes mozilla-central look easy: mozilla-central merely had one import from CVS. In contrast, comm-central imported twice from CVS (the calendar code came later), four times from mozilla-central (once with converted history), and imported twice from Instantbird's repository (once with converted history). Three of those conversions also involved moving paths. But I've worked through all of those issues to provide a nice snapshot of the repository [1]. And since I've been frustrated by failing to find good documentation on how this sort of process went for mozilla-central, I'll provide details on the process for comm-central.

The first step and probably the hardest is getting the CVS history in DVCS form (I use hg because I'm more comfortable it, but there's effectively no difference between hg, git, or bzr here). There is a git version of mozilla's CVS tree available, but I've noticed after doing research that its last revision is about a month before the revision I need for Calendar's import. The documentation for how that repo was built is no longer on the web, although we eventually found a copy after I wrote this post on I tried doing another conversion using hg convert to get CVS tags, but that rudely blew up in my face. For now, I've filed a bug on getting an official, branchy-and-tag-filled version of this repository, while using the current lack of history as a base. Calendar people will have to suffer missing a month of history.

CVS is famously hard to convert to more modern repositories, and, as I've done my research, Mozilla's CVS looks like it uses those features which make it difficult. In particular, both the calendar CVS import and the comm-central initial CVS import used a CVS tag HG_COMM_INITIAL_IMPORT. That tagging was done, on only a small portion of the tree, twice, about two months apart. Fortunately, mailnews code was never touched on CVS trunk after the import (there appears to be one commit on calendar after the tagging), so it is probably possible to salvage a repository-wide consistent tag.

The start of my script for conversion looks like this:

#!/bin/bash set -e WORKDIR=/tmp HGCVS=$WORKDIR/mozilla-cvs-history MC=/src/trunk/mozilla-central CC=/src/trunk/comm-central OUTPUT=$WORKDIR/full-c-c # Bug 445146: m-c/editor/ui -> c-c/editor/ui MC_EDITOR_IMPORT=d8064eff0a17372c50014ee305271af8e577a204 # Bug 669040: m-c/db/mork -> c-c/db/mork MC_MORK_IMPORT=f2a50910befcf29eaa1a29dc088a8a33e64a609a # Bug 1027241, bug 611752 m-c/security/manager/ssl/** -> c-c/mailnews/mime/src/* MC_SMIME_IMPORT=e74c19c18f01a5340e00ecfbc44c774c9a71d11d # Step 0: Grab the mozilla CVS history. if [ ! -e $HGCVS ]; then hg clone git+ $HGCVS fi

Since I don't want to include the changesets useless to comm-central history, I trimmed the history by using hg convert to eliminate changesets that don't change the necessary files. Most of the files are simple directory-wide changes, but S/MIME only moved a few files over, so it requires a more complex way to grab the file list. In addition, I also replaced the % in the usernames with @ that they are used to appearing in hg. The relevant code is here:

# Step 1: Trim mozilla CVS history to include only the files we are ultimately # interested in. cat >$WORKDIR/convert-filemap.txt <<EOF # Revision e4f4569d451a include directory/xpcom include mail include mailnews include other-licenses/branding/thunderbird include suite # Revision 7c0bfdcda673 include calendar include other-licenses/branding/sunbird # Revision ee719a0502491fc663bda942dcfc52c0825938d3 include editor/ui # Revision 52efa9789800829c6f0ee6a005f83ed45a250396 include db/mork/ include db/mdb/ EOF # Add the S/MIME import files hg -R $MC log -r "children($MC_SMIME_IMPORT)" \ --template "{file_dels % 'include {file}\n'}" >>$WORKDIR/convert-filemap.txt if [ ! -e $WORKDIR/convert-authormap.txt ]; then hg -R $HGCVS log --template "{email(author)}={sub('%', '@', email(author))}\n" \ | sort -u > $WORKDIR/convert-authormap.txt fi cd $WORKDIR hg convert $HGCVS $OUTPUT --filemap convert-filemap.txt -A convert-authormap.txt

That last command provides us the subset of the CVS history that we need for unified history. Strictly speaking, I should be pulling a specific revision, but I happen to know that there's no need to (we're cloning the only head) in this case. At this point, we now need to pull in the mozilla-central changes before we pull in comm-central. Order is key; hg convert will only apply the graft points when converting the child changeset (which it does but once), and it needs the parents to exist before it can do that. We also need to ensure that the mozilla-central graft point is included before continuing, so we do that, and then pull mozilla-central:

CC_CVS_BASE=$(hg log -R $HGCVS -r 'tip' --template '{node}') CC_CVS_BASE=$(grep $CC_CVS_BASE $OUTPUT/.hg/shamap | cut -d' ' -f2) MC_CVS_BASE=$(hg log -R $HGCVS -r 'gitnode(215f52d06f4260fdcca797eebd78266524ea3d2c)' --template '{node}') MC_CVS_BASE=$(grep $MC_CVS_BASE $OUTPUT/.hg/shamap | cut -d' ' -f2) # Okay, now we need to build the map of revisions. cat >$WORKDIR/convert-revmap.txt <<EOF e4f4569d451a5e0d12a6aa33ebd916f979dd8faa $CC_CVS_BASE # Thunderbird / Suite 7c0bfdcda6731e77303f3c47b01736aaa93d5534 d4b728dc9da418f8d5601ed6735e9a00ac963c4e, $CC_CVS_BASE # Calendar 9b2a99adc05e53cd4010de512f50118594756650 $MC_CVS_BASE # Mozilla graft point ee719a0502491fc663bda942dcfc52c0825938d3 78b3d6c649f71eff41fe3f486c6cc4f4b899fd35, $MC_EDITOR_IMPORT # Editor 8cdfed92867f885fda98664395236b7829947a1d 4b5da7e5d0680c6617ec743109e6efc88ca413da, e4e612fcae9d0e5181a5543ed17f705a83a3de71 # Chat EOF # Next, import mozilla-central revisions for rev in $MC_MORK_IMPORT $MC_EDITOR_IMPORT $MC_SMIME_IMPORT; do hg convert $MC $OUTPUT -r $rev --splicemap $WORKDIR/convert-revmap.txt \ --filemap $WORKDIR/convert-filemap.txt done

Some notes about all of the revision ids in the script. The splicemap requires the full 40-character SHA ids; anything less and the thing complains. I also need to specify the parents of the revisions that deleted the code for the mozilla-central import, so if you go hunting for those revisions and are surprised that they don't remove the code in question, that's why.

I mentioned complications about the merges earlier. The Mork and S/MIME import codes here moved files, so that what was db/mdb in mozilla-central became db/mork. There's no support for causing the generated splice to record these as a move, so I have to manually construct those renamings:

# We need to execute a few hg move commands due to renamings. pushd $OUTPUT hg update -r $(grep $MC_MORK_IMPORT .hg/shamap | cut -d' ' -f2) (hg -R $MC log -r "children($MC_MORK_IMPORT)" \ --template "{file_dels % 'hg mv {file} {sub(\"db/mdb\", \"db/mork\", file)}\n'}") | bash hg commit -m 'Pseudo-changeset to move Mork files' -d '2011-08-06 17:25:21 +0200' MC_MORK_IMPORT=$(hg log -r tip --template '{node}') hg update -r $(grep $MC_SMIME_IMPORT .hg/shamap | cut -d' ' -f2) (hg -R $MC log -r "children($MC_SMIME_IMPORT)" \ --template "{file_dels % 'hg mv {file} {sub(\"security/manager/ssl\", \"mailnews/mime\", file)}\n'}") | bash hg commit -m 'Pseudo-changeset to move S/MIME files' -d '2014-06-15 20:51:51 -0700' MC_SMIME_IMPORT=$(hg log -r tip --template '{node}') popd # Echo the new move commands to the changeset conversion map. cat >>$WORKDIR/convert-revmap.txt <<EOF 52efa9789800829c6f0ee6a005f83ed45a250396 abfd23d7c5042bc87502506c9f34c965fb9a09d1, $MC_MORK_IMPORT # Mork 50f5b5fc3f53c680dba4f237856e530e2097adfd 97253b3cca68f1c287eb5729647ba6f9a5dab08a, $MC_SMIME_IMPORT # S/MIME EOF

Now that we have all of the graft points defined, and all of the external code ready, we can pull comm-central and do the conversion. That's not quite it, though—when we graft the S/MIME history to the original mozilla-central history, we have a small segment of abandoned converted history. A call to hg strip removes that.

# Now, import comm-central revisions that we need hg convert $CC $OUTPUT --splicemap $WORKDIR/convert-revmap.txt hg strip 2f69e0a3a05a

[1] I left out one of the graft points because I just didn't want to deal with it. I'll leave it as an exercise to the reader to figure out which one it was. Hint: it's the only one I didn't know about before I searched for the archive points [2].
[2] Since I wasn't sure I knew all of the graft points, I decided to try to comb through all of the changesets to figure out who imported code. It turns out that hg log -r 'adds("**")' narrows it down nicely (1667 changesets to look at instead of 17547), and using the {file_adds} template helps winnow it down more easily.

Categorieën: Mozilla-nl planet

Kent James: Thunderbird Summit in Toronto to Plan a Viable Future

Thunderbird - wo, 15/10/2014 - 06:17

On Wednesday, October 15 through Saturday, October 19, 2014, the Thunderbird core contributors (about 20 people in total) are gathering at the Mozilla offices in Toronto, Ontario for a key summit to plan a viable future for Thunderbird. The first two days are project work days, but on Friday, October 18 we will be meeting all day as a group to discuss how we can overcome various obstacles that threaten the continuing viability of Thunderbird as a project. This is an open Summit for all interested parties. Remote participation or viewing of Friday group sessions is possible, beginning at 9:30 AM EDT (6:30 AM Pacific Daylight Time)  using the same channels as the regular weekly Thunderbird status meetings.

Video Instructions: See for details.

Overall Summit Description and Agenda: See

Feel free to join in if you are interested in the future of Thunderbird.

Categorieën: Mozilla-nl planet
